Pet strips coating machine is a precision equipment specially used for producing orodissolving films for pets. Its core lies in the high-precision coating technology and controllable drying process,
which evenly converts the specific drug solution into a film product with uniform thickness, fast dissolution and accurate dosage, providing a convenient and palatable way of drug administration
or nutritional supplementation for pets. It coats a uniform solvent containing active ingredients, film-forming materials, plasticizers and other excipients on a continuous release film, removes the
solvent through a precisely controlled drying process, and finally forms a film with uniform thickness and fast dissolution, and rolls it into a roll for subsequent special packaging machines to cut
and package.
Features:
Unwinding system: carries and stably releases the coating substrate---release film.
The machine is equipped with a tension control system to ensure that the tension of the material is constant during operation to avoid wrinkling or breaking.
Hot air circulation: The heated air is evenly blown to the surface and back of the film through the fan to take away the solvent vapor.
Winding system: The dried finished film rolls neatly and with constant tension.
Main Data:
Name:Pet Strips Coating Machine
Model: PPD-ODFM300
Coating width: max 300mm
Coating thickness: 0.02-0.1mm
Coating speed: 0.01-1m/min
Bottom substrate width: 360mm, Φ≤350mm, paper tube inner diameter 76.2mm
Total power: 380v 50Hz motor 1.5KW heating 16KW
Pressure: 0.6-0.8Mpa
